INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
ENVOY™ TRANSCEIVER GETTING STARTED GUIDE 165
Rack-mounting unit
A rack-mounting unit consists of a 19 inch rack tray. It can be used to
mount your fixed station with either a desk console or the handset and
cradle.
Connecting a fixed Envoy™ station
NOTE: A typical fixed station is shown in
Figure 47.
To connect a fixed station:
1 Do one of the following:
• Connect cable 08-07205-00x between the Transceiver
connector on the 2230 Desk Console and the 10-way plug
on the flying lead from the RFU, securing the locking
rings tightly into position.
CAUTION: If the desk console is connected to the RFU
via cable 08-07205-00x, ensure that an
Ethernet cable is not connected to the RJ45
connector on the rear of the desk console.
• Connect cable 08-07215-001 between the Ethernet
connector on the 2230 Desk Console, or an optional
switch/router, and the 10-way plug on the flying lead
from the RFU, securing the locking ring tightly into
position.
CAUTION: If the desk console is connected to the RFU
via an Ethernet cable and cable
08-07215-001, ensure that cable
08-07205-00x is not connected to the
8-way connector ( ) on the rear of the desk
console.
NOTE: If a switch/router is used, an additional
RJ45 cable is required to connect between
the switch/router and the desk console.
• Connect the lead from the handset and speaker connector
to the 10-way plug on the flying lead from the RFU, then
secure the locking ring tightly into position.
