OPERATING THE TRANSCEIVER
DATA OPTIONS
96 ENVOY™ TRANSCEIVER GETTING STARTED GUIDE
Figure 25: Transmit and receive screens during a
MIL/STANAG 2G data call
NOTE: An AES-256 data encryption upgrade is available
for use with the MIL/STANAG 2G Data interface.
NOTE: If you go off line in RC50-C, the modem may
disconnect for 15 sec, then reconnect.
Related links:
Using encryption on page 100
RM50e HF Data Modem
The RM50e HF Data Modem provides data communications. It may
also be used to provide high-grade AES-256 digital encryption. It may
be used with any data-capable Codan HF transceiver. It must be used in
conjunction with the RC50-C HF Email software. The data modem is
capable of high-speed data transfer at speeds of up to 9600 bit/s using
STANAG 4539 waveforms. The data modem also supports
MIL-STD-188-110A/B (including Appendix F), STANAG 4285,
STANAG 4529, and STANAG 4415 waveforms.
NOTE: When a data application is connected, an icon appears in
the status bar of the channel screen ( ).
Related links:
Using encryption on page 100
Transmit Receive
