INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 117
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Tagged VID Port MEP: An outer C/S-tag (depending on VLAN Port Type) is added with this VID. Entering '0'
means no TAG added.
EVC MEP: This is not used.
VLAN MEP: This is not used.
EVC MIP: On Serval, this is the Subscriber VID that identify the subscriber flow in this EVC where
the MIP is active.
This MAC The MAC of this MEP - can be used by other MEP when unicast is selected (Info only).
Instance Configuration
EVC Policy ID This is the Policy number of the relevant ECE. Policy ID is used to assure that received OAM PDU
is able to hit a IS2 entry. If this value is '0' IS2 rules will be created on classified VID. If this is NOT
'0' IS2 rules will be created on this Policy (PAG). This must be equal to ECE Policy Number if OAM
PDU will hit the ECE IS0. This is the case if an ECE is created with 'tag_type' as 'any'.
EVC QoS This is only relevant for a EVC MEP. This is the Qos of the EVC and used for getting QoS counters
for Loss Measurement.
Level See help on MEP create WEB.
Format This is the configuration of the two possible Maintenance Association Identifier formats.
ITU ICC: This is defined by ITU (Y1731 Fig. A3). 'Domain Name' is not used. 'MEG id' must be
max. 13 char.
IEEE String: This is defined by IEEE (802.1ag Section 21.6.5). 'Domain Name' can be max. 16 char.
'MEG id' (Short MA Name) can be max. 16 char.
ITU CC ICC: This is defined by ITU (Y1731 Fig. A5). 'Domain Name' is not used. 'MEG id' must be
max. 15 char.
Domain Name This is the IEEE Maintenance Domain Name and is only used in case of 'IEEE String' format. This
string can be empty giving Maintenance Domain Name Format 1 - Not present. This can be max
16 char.
MEG Id This is either ITU MEG ID or IEEE Short MA Name - depending on 'Format'. See 'Format'. In case
of ITU ICC format this must be 13 char. In case of ITU CC ICC format this must be 15 char. In case
of IEEE String format this can be max 16 char.
MEP Id This value will become the transmitted two byte CCM MEP ID.
Tagged VID This value will be the VID of a TAG added to the OAM PDU.
VOE This will attempt to utilize VOE HW for MEP implementation. Not all platforms support VOE.
cLevel Fault Cause indicating that a CCM is received with a lower level than the configured for this MEP.
cMEG Fault Cause indicating that a CCM is received with a MEG ID different from configured for this
M EP.
cMEP Fault Cause indicating that a CCM is received with a MEP ID different from all 'Peer MEP ID'
configured for this MEP.
cAIS Fault Cause indicating that AIS PDU is received.
cLCK Fault Cause indicating that LCK PDU is received.
cSSF Fault Cause indicating that server layer is indicating Signal Fail.
aBLK The consequent action of blocking service frames in this flow is active.
aTSF The consequent action of indicating Trail Signal Fail to-wards protection is active.
Peer MEP Configuration
Delete This box is used to mark a Peer MEP for deletion in next Save operation.
Peer MEP ID This value will become an expected MEP ID in a received CCM - see 'cMEP'.
