INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 216
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Auto_refresh Check to refresh the page automatically every 3 seconds.
Refresh Click to refresh the displayed table starting from the input fields.
MVR
Statistics
This page provides MVR Statistics information.
Object Description
VLAN ID The Multicast VLAN ID
IGMP/MLD Queries Received The number of Received Queries for IGMP and MLD, respectively.
IGMP/MLD Queries Transmitted The number of Transmitted Queries for IGMP and MLD, respectively.
IGMPv1 Joins Received The number of Received IGMPv1 Join’s.
IGMPv2/MLDv1 Report’s Received The number of Received IGMPv2 Join’s and MLDv1 Report’s, respectively.
IGMPv3/MLDv2 Report’s Received The number of Received IGMPv1 Join’s and MLDv2 Report’s, respectively.
IGMPv2/MLDv1 Leave’s Received The number of Received IGMPv2 Leave’s and MLDv1 Done’s, respectively.
Auto_refresh Check to refresh the page automatically every 3 seconds.
Refresh Click to refresh the displayed table starting from the input fields.
Clear Click to Clears all Statistics counters.
