System IP Status
This page displays the status of the IP protocol layer. The status is defined by the IP interfaces, the
IP routes and the neighbour cache (ARP cache) status.
Object Description
IP Interfaces
Interface The name of the interface.
Type The address type of the entry. This may be LINK or IPv4.
Address The current address of the interface (of the given type).
Status The status flags of the interface (and/or address).
IP Routes
Network The destination IP network or host address of this route.
Gateway The gateway address of this route.
Status The status flags of the route.
Neighbor cache
IP Address The IP address of the entry.
Link Address The Link (MAC) address for which a binding to the IP address given exist..
Auto_refresh Check to refresh the page automatically every 3 seconds.
Reset Click to refresh screen without Auto_refresh.
