UPnP
Configure UPnP on this page.
Object Description
Mode Indicates the UPnP operation mode. Possible modes are:
Enabled: Enable UPnP mode operation.
Disabled: Disable UPnP mode operation.
When the mode is enabled, two ACEs are added automatically to trap UPNP related packets to CPU.
The ACEs are automatically removed when the mode is disabled.
TTL The TTL value is used by UPnP to send SSDP advertisement messages. Valid values are in the range
1 to 255.
Advertising
Duration
The duration, carried in SSDP packets, is used to inform a control point or control points how often
it or they should receive an SSDP advertisement message from this switch. If a control point does
not receive any message within the duration, it will think that the switch no longer exists. Due to the
unreliable nature of UDP, in the standard it is recommended that such refreshing of advertisements
to be done at less than one-half of the advertising duration. In the implementation, the switch sends
SSDP messages periodically at the interval one-half of the advertising duration minus 30 seconds.
Valid values are in the range 100 to 86400.
Apply Click to apply changes.
Reset Click to revert to previous values.
