QoS Statistics
This page provides statistics for the different queues for all switch ports.
Object Description
Port The logical port for the settings contained in the same row.
Qn There are 8 QoS queues per port. Q0 is the lowest priority queue.
Rx / Tx The number of received and transmitted packets per queue
Auto_refresh Check to refresh the page automatically every 3 seconds.
Refresh Click to refresh the page.
Clear Click to clear the counters for all ports.
