INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 78
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
ARP Inspection
Port Configuration
This page provides ARP Inspection related configuration.
Object Description
Mode of ARP
Inspection
Configuration
Enable the Global ARP Inspection or disable the Global ARP Inspection.
Port Mode
Configuration
Specify ARP Inspection is enabled on which ports. Only when both Global Mode and Port
Mode on a given port are enabled, ARP Inspection is enabled on this given port. Possible
modes are:
Enabled: Enable ARP Inspection operation.
Disabled: Disable ARP Inspection operation.
If you want to inspect the VLAN configuration, you have to enable the setting of “Check
VLAN”. The default setting of “Check VLAN” is disabled. When the setting of “Check VLAN”
is disabled, the log type of ARP Inspection will refer to the port setting. And the setting
of “Check VLAN” is enabled, the log type of ARP Inspection will refer to the VLAN setting.
Possible setting of “Check VLAN” are:
Enabled: Enable check VLAN operation.
Disabled: Disable check VLAN operation.
Only the Global Mode and Port Mode on a given port are enabled, and the setting of “Check
VLAN” is disabled, the log type of ARP Inspection will refer to the port setting.
There are four log types and possible types are:
None: Log nothing.
Deny: Log denied entries.
Permit: Log permitted entries.
ALL: Log all entries.
Apply Click to apply changes.
Reset Click to revert to previous values.
Translate dynamic
to static
Click to translate all dynamic entries to static entries.
