LLDP
Neighbors
This page provides a status overview for all LLDP neighbors. The displayed table contains a row
for each port on which an LLDP neighbor is detected.
Object Description
Local Interface The port on which the LLDP frame was received.
Chassis ID The Chassis ID is the identification of the neighbor’s LLDP frames.
Port ID The Port ID is the identification of the neighbor port.
Port Description Port Description is the port description advertised by the neighbor unit.
System Name System Name is the name advertised by the neighbor unit.
System Capabilities System Capabilities describes the neighbor unit’s capabilities. The possible capabilities are:
1. Other
2. Repeater
3. Bridge
4. WLAN Access Point
5. Router
6. Telephone
7. DOCSIS cable device
8. Station only
9. Reser ved
When a capability is enabled, the capability is followed by (+). If the capability is disabled,
the capability is followed by (-).
Management Address Management Address is the neighbor unit’s address that is used for higher layer entities to
assist discovery by the network management. This could for instance hold the neighbor’s IP
address.
Auto_refresh Check to refresh the page automatically every 3 seconds.
Refresh Click to refresh the displayed table starting from the input fields.
