INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 143
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Adding a
New Group
to VLAN
MAPPING
ENTRY
Click “Add New Entry” to add a new entry in the mapping table. An empty row is added to the table,
where Frame Type, Value and the Group Name can be configured as needed.
The “Delete” button can be used to undo the addition of new entry. The maximum possible Protocol
to Group mappings are limited to 128.
Auto_refresh Check this box to automatically refresh page every 3 seconds.
Refresh Click to refresh the displayed table.
Apply Click to apply changes.
Reset Click to undo any changes made locally.
