INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 147
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Port Mode Indicates the Voice VLAN port mode. Possible port modes are:
Disabled: Disjoin from Voice VLAN.
Auto: Enable auto detect mode. It detects whether there is VoIP phone attached to the specific port
and configures the Voice VLAN members automatically.
Forced: Force join to Voice VLAN.
Port Security Indicates the Voice VLAN port security mode. When the function is enabled, all non-telephonic MAC
addresses in the Voice VLAN will be blocked for 10 seconds.
Possible port modes are:
Enabled: Enable Voice VLAN security mode operation.
Disabled: Disable Voice VLAN security mode operation.
Port Discovery
Protocol
Indicates the Voice VLAN port discovery protocol. It will only work when auto detect mode is
enabled. We should enable LLDP feature before configuring discovery protocol to “LLDP” or “Both”.
Changing the discovery protocol to “OUI” or “LLDP” will restart auto detect process. Possible
discovery protocols are:
OUI: Detect telephony device by OUI address.
LLDP: Detect telephony device by LLDP.
Both: Both OUI and LLDP.
Apply Click to apply changes.
Reset Click to revert to previous values.
