QoS Ingress Queue Policer Configuration
This page allows you to configure the Queue Policer settings for all switch ports.
The settings relate to the currently selected stack unit, as reflected by the page header.
Object Description
Port The port number for which the configuration below applies.
Enable (E) Enable or disable the queue policer for this switch port.
Rate Controls the rate for the queue policer. This value is restricted to 100-3276700 when "Unit" is kbps, and
1-3276 when "Unit" is Mbps. The rate is internally rounded up to the nearest value supported by the
queue policer.
This field is only shown if at least one of the queue policers are enabled.
Unit Controls the unit of measure for the queue policer rate as kbps or Mbps.
This field is only shown if at least one of the queue policers are enabled.
Apply Click to apply changes.
Reset Click to undo any changes made locally and revert to previously saved values.
