INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 189
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Offer Number of DHCP OFFER messages sent.
ACK Number of DHCP ACK messages sent.
NAK Number of DHCP NAK messages sent.
Auto_refresh Check to refresh the page automatically every 3 seconds.
Clear Click to clear DHCP Message Received and Sent counters.
Refresh Click to refresh the page.
Binding
This page displays bindings generated for DHCP clients.
Display all bindings.
Object Description
IP IP address allocated to DHCP client.
Type Type of binding. Possible types are Automatic, Manual, Expired.
State State of binding. Possible states are Committed, Allocated, Expired.
Pool Name The pool that generates the binding.
Server ID Server IP address to service the binding. CoS: Classify Class of Service.
Auto_refresh Check to refresh the page automatically every 3 seconds.
Clear Selected Click to clear selected bindings. If the selected binding is Automatic or Manual, then it is
changed to be Expired. If the selected binding is Expired, then it is freed.
Clear Automatic Click to clear all Automatic bindings and Change them to Expired bindings.
Clear Manual Click to clear all Manual bindings and Change them to Expired bindings.
Clear Expired Click to clear all Expired bindings and free them.
Refresh Click to refresh the page.
