INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 210
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Port Status
This page provides a status overview for LACP status for all ports.
Object Description
Port The switch port number.
LACP ‘Yes’ means that LACP is enabled and the port link is up. ‘No’ means that LACP is not enabled
or that the port link is down. ‘Backup’ means that the port could not join the aggregation group
but will join if other port leaves. Meanwhile its LACP status is disabled.
Key The key assigned to this port. Only ports with the same key can aggregate together.
Aggr ID The Aggregation ID assigned to this aggregation group.
Partner System ID The partner’s System ID (MAC address).
Partner Port The partner’s port number connected to this port.
Partner Prio The partner’s port priority.
Auto_refresh Check to refresh the page automatically every 3 seconds.
Refresh Click to refresh the displayed table starting from the input fields.
