SNMP Groups
Configure SNMPv3 group table on this page. The entry index keys are Security Model and
Security Name.
Object Description
Delete Check to delete the entry. It will be deleted during the next save.
Security Model Indicates the security model that this entry should belong to. Possible security models are:
v1: Reserved for SNMPv1.
v2c: Reserved for SNMPv2c.
usm: User-based Security Model (USM).
Security Name A string identifying the security name that this entry should belong to. The allowed string
length is 1 to 32, and the allowed content is ASCII characters from 33 to 126.
Group Name A string identifying the group name that this entry should belong to. The allowed string length
is 1 to 32, and the allowed content is ASCII characters from 33 to 126.
Apply Click to apply changes.
Reset Click to revert to previous values.
Add New Entry Click to add a new group.
