RMON
Statistics
Configure RMON Statistics table on this page. The entry index key is ID.
Object Description
Delete Check to delete the entry. It will be deleted during the next save.
ID Indicates the index of the entry. The range is from 1 to 65535.
Data Source Indicates the port ID which wants to be monitored.
Apply Click to apply changes.
Reset Click to revert to previous values.
Add New Entry Click to add new RMON statistic configurations.
History
Configure RMON History table on this page. The entry index key is ID.
Object Description
Delete Check to delete the entry. It will be deleted during the next save.
ID Indicates the index of the entry. The range is from 1 to 65535.
Data Source Indicates the port ID which wants to be monitored.
Interval Indicates the interval in seconds for sampling the history statistics data. The range is from 1 to
3600, default value is 1800 seconds.
Buckets Indicates the maximum data entries associated this History control entry stored in RMON. The
range is from 1 to 3600, default value is 50.
Buckets Granted The number of data shall be saved in the RMON.
Apply Click to apply changes.
Reset Click to revert to previous values.
Add New Entry Click to add a new history configurations.
