INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 99
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
IGMP Address Define the IPv4 address as source address used in IP header for IGMP control frames.
The default IGMP address is not set (0.0.0.0).
When the IGMP address is not set, system uses IPv4 management address of the IP interface
associated with this VLAN.
When the IPv4 management address is not set, system uses the first available IPv4 management
address.
Otherwise, system uses a pre-defined value. By default, this value will be 192.0.2.1.
Mode Specify the MVR mode of operation. In Dynamic mode, MVR allows dynamic MVR membership
reports on source ports. In Compatible mode, MVR membership reports are forbidden on source
ports. The default is Dynamic mode.
Tagging Specify whether the traversed IGMP/MLD control frames will be sent as Untagged or Tagged with
MVR VID. The default is Tagged.
Priority Specify how the traversed IGMP/MLD control frames will be sent in prioritized manner. The default
Priority is 0.
LLQI Define the maximum time to wait for IGMP/MLD report memberships on a receiver port before
removing the port from multicast group membership. The value is in units of tenths of a second. The
range is from 0 to 31744. The default LLQI is 5 tenths or one-half second.
Interface
Channel Profile
When the MVR VLAN is created, select the IPMC Profile as the channel filtering condition for the
specific MVR VLAN. Summary about the Interface Channel Profiling (of the MVR VLAN) will be
shown by clicking the view button. Profile selected for designated interface channel is not allowed
to have overlapped permit group address.
Profile
Management
Button
You can inspect the rules of the designated profile by using the following button: : List the rules
associated with the designated profile.
Port The logical port for the settings.
Port Role Configure an MVR port of the designated MVR VLAN as one of the following roles. Inactive: The
designated port does not participate MVR operations.
Source: Configure uplink ports that receive and send multicast data as source ports. Subscribers
cannot be directly connected to source ports.
Receiver: Configure a port as a receiver port if it is a subscriber port and should only receive
multicast data. It does not receive data unless it becomes a member of the multicast group by
issuing IGMP/MLD messages.
Be Caution: MVR source ports are not recommended to be overlapped with management VLAN
ports.
Select the port role by clicking the Role symbol to switch the setting.
I indicates Inactive; S indicates Source; R indicates Receiver
The default Role is Inactive.
Immediate
Leave
Enable the fast leave on the port.
Add New MVR
VLAN
Click to add a new MVR VLAN. Specify the VID and configure the new entry, then click “Apply”.
Apply Click to apply changes.
Reset Click to revert to previous values.
