Concordia XPRESS - Diagram 8, Parts List: Group Upper and Lower Piston Assembly

3033-016B Section 16: Parts Lists & Diagrams
Concordia Xpress Technical Support Manual 16-19
2900-300B
Diagram 8, Parts List: Group Upper and Lower
Piston Assembly
Diagram 8
Item #
Description
Available
Concordia
Part
Number
UPPER PISTON ASSEMBLY
30
PLATE GROUP TOP 2000/2500
YES
1110-384
KIT FUNNEL RETAINER
YES
98550
20
CLIP RETAINER FUNNEL
YES
1110-613
21
SLIDE MTG FUNNEL NSF
YES
1120-113
22
FUNNEL- GROUNDS- 2000s/i
YES
1110-357
23
BRKT FUNNEL MOUNTING 2000
YES
1110-359
ASSY- DRIVE- BREW PISTON
YES
2130-015
24
BUSHING- GROOVE RR GROUP
YES
2140-006
25
O-RING- 44.17 X 1.78
YES
2140-024
26
RING- GUIDE- RR GROUP
YES
2140-020
27
SHAFT- GUIDE- RR GROUP
YES
2140-019
29
SEAL- GROM BREW CAST NSF
YES
1260-051
33
BUSHING- BEARING RR GROUP
YES
2140-007
ASSY- UPPER PISTON SHAFT
YES
2130-010
9
PLATE- SWING BEAM
YES
2140-050
10
PIN- SWING BEAM- 8X40
YES
2140-046
11
SWING BEAM- BREWING
YES
2140-043
12
CLAMP WIRE 1/8
YES
1454-031
13
BRKT- SWING BEAM- BREW LINE
YES
1110-352
14
CONN BRASS 1/8M X 1/8T
YES
1231-029
15
PH PHIL SS M5 X 8
YES
1410-097
16
PH PHIL- SS- M6 X 25
YES
1410-096
17
ASSY- BREW LINE- 2000
YES
2790-035
ASSY- PISTON- UPPER- RR
YES
2130-009
2
FH PHIL- SS- M4 X 16
YES
1410-071
3
SHAFT- GROUP- UPPER PISTON
YES
2140-009
4
SIEVE- RR GROUP
YES
2140-013
5
PLATE-DISTRIB- UP PISTON
YES
2140-035
6
PIN- DOWEL 2X12- RR GROUP
YES
2140-027
7
O-RING- UPPER PISTON
YES
1260-093
8
PISTON- WATER- RR GROUP
YES
2140-008
LOWER PISTON ASSEMBLY
58
TUBE- SHAFT- RR GROUP
YES
2140-036
59
SPC CAP- M5 X 8
YES
1410-070
60
SPINDLE- LWR PISTON DRIVE
YES
2140-057
61
ASSY- NOZZLE- ESPRESSO
YES
2790-090
ASSY PISTON LOWER SGL
YES
2130-023
52
CARRIER- SIEVE- RR GROUP
YES
2140-037
54
E-CLIP- LOWER PISTON
YES
2140-048
KIT- LWR PISTON SIEVE
YES
98436
53
O-RING-LWR PISTON-CARRIER
YES
2140-023
55
SEAL PISTON 2.5K
YES
1260-093
56
RING- WIPING- LWR PISTON
YES
1260-091
57
HOLDER- LWR PISTON SIEVE
YES
2140-059
