Concordia XPRESS - DC Board Assembly

Section 3: Electrical 3033-003B
3-6 Concordia Xpress Technical Support Manual
2900-300B
DC Board Assembly
GREEN
REG 5V
RED
38VS1
RED
38VS2
RED
24VS1
RED
24VS2
RED
15VS
RED
12VS
RED
12V
RED
VCC
RED
RFR1
RED
RFR2
RED
RFR3
RED
N12V
38VS1 38VS2 24VS1 24VS2 15VS 12VS 12V REG 5V VCC REGN12V N12V RFRDRV1 RFRDRV2 RFRDRV3 RFRGND GND
F19 FUSE F18 FUSE F17 FUSE F16 FUSE F15 FUSE
GND
240VAC
220VAC
200VAC
DC POWER SUPPLY
TEST POINTS
LED'S
DC FUSES
DC JUMPER PLUG
