Concordia XPRESS - Fuses

3033-003B Section 3: Electrical
Concordia Xpress Technical Support Manual 3-3
2900-300B
Fuses
Fuses are located on the lower AC board, middle AC board, DC board,
and rear grinder panel.
Location/Purpose
Fuse
Lower AC Board
Two 5amp fuses protect the transformer
F1 and F2
Middle AC Board
Two 5amp Slo Blo Fuses protect the grinders
Two 5amp Slo Blo Fuses protect pump
F1 and F2
F3 and F4
DC Board
Five 5amp Fuses (can shaped) protect DC components
CPU, Display, and Transducer
CPU, ICs, Display, AC Interface, DC Board, Hall-Effect
Sensors
Transducer, Display, CPU, Analog Board, Steam Tank,
Level Sensor
Fans, Valves, Relays, Main AC Contactor
F15
F16
F17
F18
Group Motors
F19
Rear Grinder Panel
Two 20amp ceramic fuses per element protect the
machine in the event the heating element shorts out.
Block
