Section 9: Flavor System 3033-009B
9-10 Concordia Xpress Technical Support Manual
2900-300B
Replacing the Syrup Manifold
1. Re-install all flavor tubing.
NOTE: Ensure the end of the tube goes completely over the
barbed fitting.
2. Attach a Ty-Wrap to each tube, between the barbed end and the
top of the hex fitting.
3. Re-install the elbow fitting.
4. Re-install the adapter.
5. Place the new syrup manifold assembly on top of the milk bowl.
NOTE: Ensure the o-ring between the milk bowl and syrup
manifold is in the correct position. The o-ring should fit into the
groove smoothly and should not be pinched.
6. Re-align the syrup manifold atop the milk bowl.
7. Re-attach the syrup manifold to the milk bowl, using the three
screws.
8. Prime the syrup system. See the Priming the Flavor Delivery
System topic on page 9-12 for instructions.
Cleaning the Flavor Delivery System
The flavor system must be cleaned under the following circumstances:
Cross-contamination of a flavor tube
During a Preventive Maintenance call
Replacing the syrup manifold
The Flavor Delivery System Cleaning Process
Use rubber gloves, protective eye wear, and clothing protection while
performing this process.
1. Press the service switch into the CLEAN position.
2. Place an open half-gallon container under the product outlet and
press the HOT WATER button on the right door to fill the
container with hot water. If the machine has a steam wand,
navigate to TEST ROUTINES > HOT WATER VALVE and press
the upper right arrow to fill the container with hot water.
3. Mix two packets of CLEANER #1 into the container of hot water.
Stir until cleaner is dissolved.
4. Disconnect the flavor tube nozzles from the flavor boxes and
place them in the CLEANER #1 cleaning solution.
NOTE: To maintain a clean workspace, place a clean cloth
under the flavor box connectors to catch any drips.
5. Enter the software menu and navigate to MISCELLANEOUS >
RUN SYRUP CLEAN. Press the upper right arrow button to start
the syrup clean process.
NOTE: Ensure all flavor tube nozzles remain completely
submerged during the cleaning cycle.
6. Once the cycle completes, place the flavor tube nozzles on a
clean towel, and then empty and rinse the container.
7. Refill the container with hot water as in step 2 above.
