Concordia XPRESS - Diagram 9, Parts List: Group Drive System

3033-016B Section 16: Parts Lists & Diagrams
Concordia Xpress Technical Support Manual 16-21
2900-300B
Diagram 9, Parts List: Group Drive System
Diagram 9
Item #
Description
Available
Concordia
Part
Number
34
ASSY- GRP MTR BREW PIST
YES
2130-013
35
ASSY- GRP MTR COFFEE PIST
YES
2130-012
36
SCREW- ALLEN SET- M6X20
YES
2140-002
37
ASSY- CASTING- GROUP
YES
2130-017
38
BOLT- HELICAL GROOVE
YES
2140-003
39
ASSY GROUP TOP PLATE 2000
YES
1110-299
30
PLATE- GROUP TOP- 2000
YES
1110-384
40
SLEEVE- BREW CHAMBER
YES
2140-065
41
HALL BRACKET
YES
2140-033
42
ASSY- HALL SENSOR- 995
YES
2130-003
43
SOC CAP SS M3 X 5
YES
1410-073
44
BOLT- DISTANCE- BRASS
YES
2140-032
45
PLATE- FASTENING
YES
2140-034
46
DRIVE DUAL W/SPINDLE & CAST
YES
2130-014
47
SCREW- ALLEN- M6X65
YES
2140-004
48
PIN- M- AMP- MED
YES
1353-009
49
HSG- AMP- 3PIN M- WHT
YES
1353-003
50
HSG- AMP- 4PIN M- WHT
YES
1353-004
