1.8.3.1 Tubing Set without Bur Irrigation (E9414) for use with the CoolFlex High
Speed Drill
The E9414 Tubing Set is used in conjunction with the CoolFlex Drill only to provide cooling for the
handpiece body.
Cooling for the handpiece body is recommended at all times and is obtained from a supply of sterile
fluid (water or saline) that is pumped to the body of the handpiece.
1. Spike Line — Connects to the fluid supply for fluid distribution to the surgical site.
2. Priming Chamber — Used to prime the tubing line.
3. Cassette - Attaches to the peristaltic pump of the controller to aid in fluid delivery.
4. Handpiece Cassette — Connects to the handpiece body to supply fluid for handpiece cooling.
Also redirects fluid for recirculation back to the fluid supply.
5. Recirculating Line — Routes the fluid back to the supply bag for recirculation.
6. Handpiece Cord Clips — Used to attach the tubing to the handpiece cord.
