83
MICROCHOICE
HANDPIECES
C
(b) Depress the Activation Lever or
appropriate footswitch pedal.
(c) Place the handpiece back in the
“SAFE” position.
(d) Retighten the blade locking collar.
4. To change operating speeds, reference
“2.1.5 Controller Operation” on page 48
if using Port 2 of the Advantage controller
or “3.6.5.1 Handpiece Cord Button
Operation Using the Elite High Speed
Drill, Medium Speed Drill, Saws and
Modular Handpiece” on page 93.
5. To remove blades:
(a) Place the “SAFE/RUN” Slide in the
“SAFE” position.
(b) Twist the blade lock collar counter-
clockwise and remove the blade.
3.5.2 Sagittal Saw (5022-022)
Operation
NOTE: Use only Hall 5023 series blades.
PRECAUTIONS:
1. The blade collet lock mechanism
must be completely closed to ensure the
blade is held firmly in place.
2. Do not use the XL Handpiece Activation
Lever (5020-059) with the Sagittal Saw.
Warning: When using the PowerPro
Sagittal Saw attachment (PRO2043),
placing excessive bending or twisting
force on the sagittal saw blade may cause the
collet to open and release the saw blade. Do
not use saw blades to pry, remove bone
grafts, or as a leverage point. Patient or user
injury could occur.
1. To attach blades:
(a) Place the “SAFE/RUN” Slide in the
“SAFE” position.
(b) Depress the collet lock mechanism to
open the collet. Position the blade on
the pins inside the collet.
To Next Page
