47
CONTROLLER
OPERATION
A
2.1.4 Tubing Set Cassette Installation
If using irrigation (recommended when using
the CoolFlex High Speed Drill) use surgical
aseptic techniques to attach the tubing set as
follows (Advantage controller shown):
1. Circulator - Open the tubing package.
Present the package contents to the Scrub.
2. Scrub - Remove the tubing set from its
sterile package and pass the black cassette
and bag spike line out of the sterile field to
the Circulator.
3. Circulator - Position the cassette over the
pump rotor on the controller with the tubing
facing down and the black tab behind the
metal plate.
4. Slide the cassette down until it snaps into
place.
5. Remove the cap from the bag spike and
pierce the sterile fluid bag connector.
6. To remove the cassette, pull out on the
black tab at the bottom of the cassette.
7. After use, dispose of tubing set
properly.
