71
E9000
HANDPIECES
B
3.2.5 Handpiece Adjustment
The CoolFlex High Speed Drill can be adjusted
to a 20° angle, without the use of a separate
attachment, for access to hard to reach areas.
PRECAUTION: The handpiece
should only be operated in the 0° or
20° position, not at any other angle.
Damage to the handpiece will occur.
NOTE: Unless the angled position is needed,
or when aggressive cutting is required, it is
recommended that the CoolFlex High Speed
Drill be operated in the straight position for
optimal operation and cooling.
1. To adjust the angle of the handpiece:
(a) Grasp the main handpiece body and the
keyless chuck.
(b) Press the collet locking button to
unlock the chuck.
(c) Twist the keyless chuck clockwise
while twisting the main body in the
opposite direction until the collet
locking button clicks into place.
3.3 Cranial Perforator Drive
(E9015) Operation
NOTES:
1. The handpiece cord button and all front
panel buttons are disabled when using
the E9015 Cranial Perforator Drive.
2. The Cranial Perforator Drive operates
only in the forward direction up to 750
rpm and has no oscillate or reverse mode.
3. The Cranial Perforator Drive accepts
Hudson shank accessories.
1. To insert a perforator cutter:
(a) Retract the chuck sleeve.
(b) Insert the perforator cutter into the
chuck until it is fully seated.
(c) Release the chuck sleeve to lock the
perforator cutter in place.
(d) Pull on the perforator cutter to ensure it
is securely locked in place.
2. To activate the handpiece, depress either the
left or right footswitch pedal.
