103
MINI-DRIVER
HANDPIECE
E
NOTE: On attachments that contain
alignment pins, guide the alignment pin into
one of the four available slots on the
nosepiece.
(d) To remove the attachment, repeat steps
1(a) and 1(b) and pull out the
attachment.
3.10.3 Pin and Wiredriver Attachments
Insertion of pins and wires, and the functionality
of the handpiece with either pins or wires, is the
same with either attachment.
3.10.3.1 Pin Driver Attachment (K211)
The Automatic Pin Driver is designed to drive
pins (wires) and drill bits compatible with the
specifications below:
Through Cannulation: 1.6 - 4.0 mm
(0.062 in to 0.156 in.)
(1/16 - 5/32 in.)
Nosepiece
Pin Grasping Lever
Adjustment Sleeve
To Next Page
