3.5.3 Oscillating Saw (5020-024)
Operation
NOTE: Use only Hall 5023 series blades.
1. To attach saw blades:
(a) Place the “SAFE/RUN” Slide in the
“SAFE” position.
(b) Twist the blade lock collar until the
arrows are no longer aligned in the
“LOCK” position.
(c) Position the blade on the pins inside the
collet.
(d) Twist the blade lock collar and align
the arrows in the “LOCK” position to
secure the blade.
PRECAUTION: The blade lock collar
must be completely closed to ensure
the blade is held firmly in place.
2. Blades may be positioned at 45° intervals
within a 360° circumference of the collet.
3. Verify the blade is securely attached by
briefly activating the handpiece.
