D-Link DWL-6600AP User Manual

Configuring SNTP Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 105
D-Link UWS User Manual
Summer Time Recurring Configuration
Clicking the Recurring check box indicates that the configuration is to be repeated every year. When you select
Recurring, the fields shown in the following table occur.
Figure 36: Summer Time Recurring Configuration
Table 31: Summer Time Recurring Configuration Fields
Field Description
Summertime Enable or disable summer time mode.
Recurring Select the check box to indicate that the configuration is to be repeated every year.
Location This field displays only when the Recurring check box is selected. The summer time
configuration is predefined for the United States and European Union. To set the summer
time for a location other than the USA or EU, select None.
Offset Set the number of minutes to add during summer time in the range 0 to 1440.
Zone Set the acronym of the time zone to be displayed when summer time is in effect. The range
is 0 to 4 characters.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
