Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 531
D-Link UWS User Manual
Viewing RRM Neighbors
The RRM Neighbors Summary page shows neighbor information for each VAP. This table is visible only from
the Cluster Controller. The Cluster Controller builds the neighbor summary table from RF Scan reports, from
the list of managed APs in the cluster, and from the information available in the profile configuration database.
Use the drop-down menu to view RRM neighbors for a specific AP (identified by MAC address) or to view RRM
neighbors for all APs.
Figure 350: RRM Neighbors
The following table describes the fields on the RRM Neighbors Summary page.
Command Buttons
The page includes the following button:
• Delete All—Remove all entries from the list.
• Refresh—Updates the page with the latest information.
Table 318: RRM Neighbors Summary
Field Description
AP MAC Address The MAC address of the managed AP.
VAP MAC Address The VAP on the managed AP to which the neighbors apply.
Neighbor MAC Address The MAC address of the detected neighbor VAP.
RSSI The signal strength with which this neighbor is detected
SSID Network name on which the VAP and the neighbor are operating.
Channel Channel on which the neighbor is operating.
Age Number of seconds since the neighbor AP was detected and reported via the RF-Scan
report.
