D-Link UWS User Manual
Authentication List Summary
Use the Authentication List Summary page to view information about the authentication lists on the system
and which users are associated with each list. The page also displays information about 802.1X port security
users.
To access the Authentication List Summary page, click LAN > Monitoring > Authentication List Summary in the
navigation tree.
Figure 20: Login Session
The Authentication List Summary page has the following fields:
Table 15: Login Fields
Field Description
Login Authentication List Displays all login authentication profiles
Method List Shows the order of the login methods configured for the list. Possible options
are:
• Enable: uses the enable password for authentication.
• Line: uses the Line password for authentication.
• Local:- the user's locally stored ID and password will be used for
authentication
• None: the user is not authenticated
• Radius: the user's ID and password will be authenticated using the RADIUS
server instead of locally
• TACACS+: the user's ID and password will be authenticated using the
TACACS+ server
Remove Removes the authentication profile when checked.
