D-Link DWL-6600AP User Manual

Configuring Time Ranges
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 143
D-Link UWS User Manual
Time Range Entry Configuration
Use this page to configure periodic and absolute time range entries and add them to named time ranges.
To access this page, click LAN > Administration > Time Range > Time Range Entry Configuration.
Figure 65: Time Range Entry Configuration
Note: The time range entries use the system time for the time periods in which they take effect.
Make sure you configure the SNTP server settings so that the SNTP client on the switch can obtain
the correct date and time from the server.
Table 57: Time Range Entry Configuration
Field Description
Time Range Name Select the name of the time range to which you want to add a time range
entry.
Time Range Entry Select Create New Time Range Entry to add a new entry to a time range. To
view or delete an existing time range entry, select its ID from the menu.
Time Range Entry ID When creating a new time range entry, assign a unique ID number from 1–10.
This field does not appear if the entry has already been configured.
Time Range Entry Type. Specifies whether the entry is periodic or absolute. A periodic entry occurs at
the same time every day or on one or more days of the week. An absolute
entry does not repeat.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
