D-Link DWL-6600AP User Manual

Locating WLAN Devices
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 651
D-Link UWS User Manual
Figure 408: Building
The following table shows the fields available on the Building page.
Command Buttons
The page includes the following buttons:
• Delete— Deletes the selected building from the database.
• Delete All—Deletes all buildings configured in the database.
• Refresh—Updates the page with the latest information.
Table 374: Building
Field Description
Building Number Unique number from 1–8 that identifies a building within the wireless
system.
Building Description A description for the building, such as an address or function. The
name can be up to 64 characters. The default name is Building-n,
where n is the building number.
Total Floor Count Number of floors configured for the building.
Total AP Count Number of APs in the building with an administratively-configured
physical location.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
