Configuring Dynamic ARP Inspection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 275
D-Link UWS User Manual
DAI VLAN Configuration
Use the DAI VLAN Configuration page to select the DAI-capable VLANs for which information is to be displayed
or configured.
To display the DAI Configuration page, click LAN > L2 Features>Dynamic ARP Inspection > DAI VLAN
Configuration in the navigation tree.
Figure 172: Dynamic ARP Inspection VLAN Configuration
Click Submit to apply the new configuration and cause the change to take effect. These changes will not
be retained across a power cycle unless a Save configuration is performed.
Click Refresh to refresh the page with the most current data from the switch.
Table 155: Dynamic ARP Inspection VLAN Configuration
Field Description
VLAN ID Select the VLAN ID for which information is to be displayed or configured.
Dynamic ARP
Inspection
Select whether Dynamic ARP Inspection is Enabled or Disabled on this VLAN. The default
is Disable.
Logging Invalid
Packets
Select whether Dynamic ARP Inspection logging is Enabled or Disabled on this VLAN. The
default is Disable.
ARP ACL Name The name of the ARP Access List. A VLAN can be configured to use this ARP ACL containing
rules as the filter for ARP packet validation. The name can contain 1-31 alphanumeric
characters.
Static Flag Use this flag to determine whether the ARP packet needs validation using the DHCP
snooping database, in case the ARP ACL rules do not match. If Enabled, then the ARP
Packet will be validated by the ARP ACL Rules only. If Disabled, then the ARP Packet needs
further validation by using the DHCP Snooping entries. The default is Disable.
