D-Link DWL-6600AP User Manual

RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 418
D-Link UWS User Manual
Viewing Named Accounting Server Status
The RADIUS Named Accounting Server Status page shows summary information about the accounting servers
configured on the system.
Figure 288: RADIUS Named Accounting Server Status
Click Refresh to update the page with the most current information.
Table 246: Named Accounting Server Fields
Field Description
RADIUS Accounting Server
Name
Shows the RADIUS accounting server name.
Multiple RADIUS accounting servers can have the same name. In this case,
RADIUS clients can use RADIUS servers with the same name as backups for
each other.
IP Address Shows the IP address of the RADIUS server.
Port Number Identifies the authentication port the server uses to verify the RADIUS server
authentication. The port is a UDP port.
Secret Configured Indicates whether the shared secret for this server has been configured.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
