D-Link DWL-6600AP User Manual

HTTP Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 77
D-Link UWS User Manual
HTTP Configuration
Use the HTTP Configuration page to configure the HTTP server settings on the system.
To access the HTTP Configuration page, click LAN > Administration > HTTP Configuration in the navigation
menu.
Figure 17: HTTP Configuration
• If you make changes to the page, click Submit to apply the changes to the system.
Table 12: HTTP Configuration Fields
Field Description
HTTP Admin Mode This select field is used to Enable or Disable the Administrative Mode of HTTP.
The currently configured value is shown when the web page is displayed. The
default value is Enable. If you disable the HTTP admin mode, access to the web
interface is limited to secure HTTP, which is disabled by default.
Java Mode This select field is used to Enable or Disable the web Java Mode. This applies
to both secure and un-secure HTTP connections. The currently configured
value is shown when the web page is displayed. The default value is Enable.
HTTP Session Soft Timeout This field is used to set the inactivity timeout for HTTP sessions. The value
must be in the range of (0 to 60) minutes. A value of zero corresponds to an
infinite timeout. The default value is 5 minutes. The currently configured value
is shown when the web page is displayed.
HTTP Session Hard Timeout This field is used to set the hard timeout for HTTP sessions. This timeout is
unaffected by the activity level of the session. The value must be in the range
of (0 to 168) hours. A value of zero corresponds to an infinite timeout. The
default value is 24 hours. The currently configured value is shown when the
web page is displayed.
Maximum Number of HTTP
Sessions
This field is used to set the maximum allowable number of HTTP sessions. The
value must be in the range of (0 to 16). The default value is 16. The currently
configured value is shown when the web page is displayed.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
