Loopback Interfaces
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 303
D-Link UWS User Manual
Loopbacks Summary
Use the Loopbacks Summary page to display a summary of configured loopbacks.
To display the page, click LAN > Monitoring > L3 Status > Loopback Summary in the navigation tree.
Figure 193: Loopbacks Summary
• Click Refresh to update the information on the screen.
Table 176: Loopbacks Summary Fields
Field Description
Loopback Interface The ID of the configured loopback interface.
Addresses A list of the addresses configured on the loopback interface.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
