RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 411
D-Link UWS User Manual
RADIUS Settings
Remote Authorization Dial-In User Service (RADIUS) servers provide additional security for networks. The
RADIUS server maintains a user database, which contains per-user authentication information. RADIUS servers
provide a centralized authentication method for:
Telnet Access
Web Access
Console Access
Port Access Control (802.1X)
RADIUS Configuration
Use the RADIUS Configuration page to view and configure various settings for the RADIUS servers configured
on the system.
To access the RADIUS Configuration page, click LAN > Security > RADIUS > RADIUS Configuration in the
navigation menu.
Figure 281: RADIUS Configuration
Table 242: RADIUS Configuration Fields
Field Description
Number of Configured
Authentication Servers
The number of RADIUS authentication servers configured on the system. The
value can range from 0 to 32.
Number of Configured
Accounting Servers
The number of RADIUS accounting servers configured on the system. The
value can range from 0 to 32.
Number of Named
Authentication Server Groups
The number of authentication server groups configured on the system. An
authentication server group contains one or more configured authentication
servers that share the same RADIUS server name.
