Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 511
D-Link UWS User Manual
Viewing Associated Client Session Summary Statistics
The statistics on the WLAN > Monitoring > Client > Associated Clients > Statistics > Session Summary page
show information about the traffic a wireless client receives and transmits while it is connected to the same
WLAN network shared by APs that the switch manages.
Figure 335: Associated Client Statistics Session Summary
If the client roams from one AP to another AP but remains connected to the same network, the session
continues and the session statistics continue to accumulate. If the client closes the wireless connection or
roams out of the range of an AP managed by the switch, the session ends.
Command Buttons
The page includes the following button:
Refresh—Updates the page with the latest information.
Table 303: Associated Client Session Summary Statistics
Field Description
MAC Address The Ethernet address of the client station.
Packets Received Packets received from the client station.
Bytes Received Total bytes received from the client station.
Packets Transmitted Total packets transmitted to the client station.
Bytes Transmitted Total bytes transmitted to the client station.
