D-Link DWL-6600AP User Manual

Viewing Multicast Forwarding Database Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 242
D-Link UWS User Manual
MFDB Statistics
Use the multicast forwarding database Stats page to view statistical information about the MFDB table.
To access the Stats page, click LAN > Monitoring > Multicast Forwarding Database > Statistics in the
navigation tree.
Figure 147: Multicast Forwarding Database Statistics
• Click Refresh to update the information on the screen with the most current data.
Table 131: Multicast Forwarding Database Statistics Fields
Field Description
Max MFDB Entries Shows the maximum number of entries that the Multicast Forwarding
Database table can hold.
Most MFDB Entries Since Last
Reset
The largest number of entries that have been present in the Multicast
Forwarding Database table since the system was last reset. This value is also
known as the MFDB high-water mark.
Current Entries Shows the current number of entries in the Multicast Forwarding Database
table.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
