D-Link DWL-6600AP User Manual

Managing LLDP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 272
D-Link UWS User Manual
LLDP-MED Remote Device Information
This page displays information on LLDP-MED information received from remote clients on the selected local
interface. To display this page, click LAN > Monitoring > LLDP Status > LLDP-MED > Remote Device
Information in the navigation tree.
Figure 170: LLDP Remote Device Information
Table 153: LLDP-MED Remote Device Information Fields
Field Description
Local Interface Specifies the list of all the ports on which LLDP-MED is enabled.
Remote ID Specifies the remote client identifier assigned to the remote system.
Capability Information Specifies the supported and enabled capabilities that were received in MED
TLV on this port:
• Supported Capabilities: Specifies supported capabilities that were
received in MED TLV on this port.
• Enabled Capabilities: Specifies enabled capabilities that were received in
MED TLV on this port.
• Device Class: Specifies device class as advertised by the device remotely
connected to the port.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
