D-Link DWL-6600AP User Manual

Managing and Viewing Logs
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 123
D-Link UWS User Manual
Syslog Configuration
Use the Syslog Configuration page to allow the switch to send log messages to the remote logging hosts
configured on the system.
To access the System Log Configuration page, click LAN > Administration > Log > System Log Configuration in
the navigation tree.
Figure 50: System Log
• If you make any changes to the page, click Submit to apply the change to the system.
Table 42: Syslog Configuration Fields
Field Description
Admin Status Specifies whether to send log messages to the remote syslog hosts configured on the
switch:
• Enable: Messages will be sent to all configured hosts (syslog collectors or relays)
using the values configured for each host. For information about syslog host
configuration, see “Hosts Configuration” on page 119.
• Disable: Stops logging to all syslog hosts. Disable means no messages will be sent
to any collector/relay.
Local UDP Port Specifies the port on the switch from which syslog messages are sent. The default
port is 514.
Messages Received The number of messages received by the log process. This includes messages that are
dropped or ignored.
Messages Dropped The number of messages that could not be processed due to error or lack of
resources.
Messages Relayed The number of messages forwarded by the syslog function to a syslog host. Messages
forwarded to multiple hosts are counted once for each host.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
