Configuring ARP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 291
D-Link UWS User Manual
The ARP Table displays at the bottom of the page, and contains the following fields:
• If you make any changes to the page, click Submit to apply the changes to the system.
Peak Total Entries Highest value reached by Total Entry Count. This counter value is restarted
whenever the ARP table Cache Size value is changed.
Active Static Entries Total number of active static entries in the ARP table.
Configured Static Entries Total number of configured static entries in the ARP table.
Maximum Static Entries Maximum number of static entries that can be defined.
Remove from Table Allows you to remove certain entries from the ARP Table. The choices listed
specify the type of ARP Entry to be deleted:
• All Dynamic Entries
• All Dynamic and Gateway Entries
• Specific Dynamic Gateway Entry
• Specific Static Entry
Remove IP Address This field appears only if you select Specific Dynamic/Gateway Entry or
Specific Static Entry in the Remove from Table menu. This field allows you to
enter the IP Address against the entry that is to be removed from the ARP
Table.
Table 169: ARP Table Fields
Field Description
IP Address The IP address of a device on a subnet attached to one of the switch's routing interfaces.
MAC Address The unicast MAC address for the device. The format is six two-digit hexadecimal numbers
separated by colons, for example 00:06:29:32:81:40.
Slot/Port The routing interface associated with the ARP entry.
Type The type of the ARP entry.
Age Age since the entry was last refreshed in the ARP Table. The format is hh:mm:ss
Table 168: ARP Table Configuration Fields (Cont.)
Field Description

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
