D-Link DWL-6600AP User Manual

Basic Setup
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 549
D-Link UWS User Manual
Radio Configuration
In order to accommodate a broad range of wireless clients and wireless network requirements, the
DWL-8600AP and DWL-6600AP support two radios. Radio 1 can broadcast in one of the following modes:
• IEEE 802.11a mode
• IEEE 802.11a and IEEE 802.11n modes
• 5 GHz IEEE 802.11n mode
Radio 2 can broadcast in one of the following modes:
• IEEE 802.11b and IEEE 802.11g modes
• IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n modes
• 2.4 GHz IEEE 802.11n mode
The DWL-3600AP supports one radio that can broadcast in one of the following modes:
• IEEE 802.11b and IEEE 802.11g modes
• IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n modes
• 2.4 GHz IEEE 802.11n mode
You configure the default radio settings from the WLAN > Basic Setup > Radio tab, which the following figure
shows.
Figure 359: Radio Settings
The DWL-3600AP is a single-radio AP. Any settings you configure for Radio 1 (802.11a/n) are not
applied to the DWL-3600AP.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
