D-Link DWL-6600AP User Manual

Configuring SNTP Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 106
D-Link UWS User Manual
Clock Detail
Use the Clock Detail page to view information about the current time, time zone, and summer time settings.
To display the Clock Detail page, click LAN > Monitoring Clock Detail in the navigation menu. The following
figure shows the Clock Detail page when Summertime is enabled.
Figure 37: Clock Detail
• Click Refresh to update the page with the most current information.
Table 32: Clock Detail
Field Description
Current Time This section displays the current time.
Time Zone This section displays the time zone settings.
Summertime This section displays the summer time settings.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
