D-Link DWL-6600AP User Manual

Port Access Control
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 421
D-Link UWS User Manual
• If you change the mode, click Submit to apply the new settings to the system.
Port Configuration
Use the Port Access Control Port Configuration page to enable and configure port access control on one or
more ports.
To access the Port Based Access Control Port Configuration page, click LAN > Security > Port Access Control >
Port Configuration in the navigation menu.
Figure 292: Port Access Control Port Configuration
Dynamic VLAN Creation Mode Select Enable to allow the switch to dynamically create a RADIUS-assigned
VLAN if it does not already exist in the VLAN database.
Monitor Mode Select Enable to permit network access even when the 802.1X authentication
process fails. The switch logs the results of the authentication process for
diagnostic purposes.
Monitor Mode can help you troubleshoot Dot1X configuration problems
without affecting network access for end users.
Table 247: Global Port Access Control Configuration Fields (Cont.)
Field Description

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
