D-Link DWL-6600AP User Manual

Port Access Control
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 433
D-Link UWS User Manual
Port Access Privileges
Use the Port Access Control Privileges page to grant or deny port access to users configured on the system.
To access the Port Based Access Control Privileges page, click LAN > Security > Port Access Control > Port
Access Privileges in the navigation menu.
Figure 300: Port Access Privileges
Table 255: Port Access Privileges Fields
Field Description
Port Selects the port to grant or deny access. To grant or deny port access
privileges to a user on all ports, select All from the drop-down menu.
Users Lists the users configured on the system. The users that are highlighted have
access to the selected port. By default, all users have access to all ports. To
deny access to a port, Shift + click to select only the users to allow access.
Make sure the username to deny port access is not selected, and then click
Submit.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
