D-Link DWL-6600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 455
D-Link UWS User Manual
Viewing the Peer Switch Configuration Received Status
The Peer Switch Configuration feature allows you to send the critical wireless configuration from one switch
to all other switches. In addition to keeping the switches synchronized, this function enables the administrator
to manage all wireless switches in the cluster from one switch. The Peer Switch Configuration Received Status
page provides information about the configuration a switch has received from one of its peers.
Figure 306: Configuration Received
Table 258 describes the fields on the Wireless Global Status page.
Table 261: Peer Switch Configuration
Field Description
Current Receive Status Indicates the global status when wireless configuration is received from a peer
switch. The possible status values are as follows:
• Not Started
• Receiving Configuration
• Saving Configuration,
• Applying AP Profile Configuration
• Success
•Failure — Invalid Code Version
•Failure — Invalid Hardware Version
•Failure — Invalid Configuration
Last Configuration Received
Peer Switch IP Address Indicates the last switch from which this switch received any wireless configuration
data.

D-Link DWL-6600AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	450 Mbit/s
Power consumption (typical)	9.6 W
Internal	No
Placement	Ceiling, Wall
Certification	FCC Class B, CE Class B, C-Tick
Product color	Gray
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2

Weight and Dimensions

Depth	77.5 mm
Width	156 mm
Height	- mm
Weight	500 g
