Configuring and Viewing ISDP Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 151
D-Link UWS User Manual
Interface Configuration
From the ISDP Interface Configuration page, you can configure the ISDP settings for each interface. To display
the ISDP Cache Table page, click LAN > Administration > ISDP > Interface Configuration in the navigation tree.
Figure 72: ISDP Interface Configuration
The following table describes the fields available on the ISDP Interface Configuration page.
Holdtime Displays the ISDP holdtime for the neighbor.
Capability Displays the ISDP Functional Capabilities for the neighbor.
Platform Displays the ISDP Hardware Platform for the neighbor.
Port ID Displays the ISDP port ID string for the neighbor.
Protocol Version Displays the ISDP Protocol Version for the neighbor.
Last Time Changed Displays when entry was last modified.
Note: If ISDP is enabled on an interface, it must also be enabled globally in order for the interface to
transmit ISDP packets. If the ISDP mode on the ISDP Global Configuration page is disabled, the
interface will not transmit ISDP packets, regardless of the mode configured on the interface.
Table 64: ISDP Interface Configuration
Field Description
Slot/Port Select the interface with the ISDP mode status to configure or view.
ISDP Mode Use this field to enable or disable the Industry Standard Discovery Protocol on
the selected interface.
Table 63: ISDP Cache Table (Cont.)
Field Description
