4.3.6.1 Surround Decoder Operation
The RS20i monitors the selected input signal to determine the type of audio signal received. If a DTS,
DTS-HD or Dolby Digital bitstream is detected, the RS20i decodes the audio and places it on the first 8
channels (see Table 10, below).
If an un-encoded digital signal is received (such as 2-channel PCM), the signal is routed to the first two
channels in the RS20i (Left and Right) and the others remain muted. The HDMI also supports 6 or 8
channel un-encoded PCM signal. The RS20i will switch between stream types as the signal type
changes. This occurs automatically within the RS20i.
Table 10. Decoder Channel Assignments
Channel
Number
channel name
1 Left (L)
2 Right (R)
3 Center (C)
4 Sub Woofer (SW)
5 Left Surround (Ls)
6 Right Surround (Rs)
7 Left Back (Lb)
8 Right Back (Rb)
9 High Left (HL)
10 High Right (HR)
11 High Left Surround (HLs) or Left Wide (Lw)
12 High Right surround (HRs) or Right Wide (Rw)
13 —
14 —
15 High Center (HC)
16 Top (T)
